Remanufactured Axle Assembly Dana 80 11.25 Inch 4.30 Ratio Anti-spin differential with Dual Rear Wheels

SKU
435-204CP
Price
$3,425.00
Core Charge
$1,500.00
Features and Benefits
United States Powertrain Offers Open, Non-locking or Posi-traction, Locking Units Available, All Gear Ratios Available.
Installation Instructions
INS_FORM.docx (171.9 KB)
Notes
Brand: US Powertrain

OEM Replacement Stock Dana 80 11.25 inch,4.30 ratio, anti-spin differential
2008-2016 Ford F-350 Super Duty, 2008-2016 Ford F-350
Differential
Axle Type: Rear Differential
Cover Bolt Quantity: 10
Gear Ratio: 4.30
Mounting Hardware Included: No
Ring Gear Outside Diameter: 11.25 Inch
with Dual Rear Wheels (DRW), with Posi-Traction, with 4.30 Gear Ratio, Spring to Spring= 42", Brake flange to flange="54.5

Warranty Time: 1 Months

Applications:

  • 2008-2016 Ford F-350 Super Duty - PartType: Differential - Position: Rear
  • 2011-2016 Ford F-350 - PartType: Differential - Position: Rear
Warranty
US POWERTRAIN standard warranty for cars and light truck up to and including 1 ton is 36 months/36,000 miles. All commercial, farm and larger than 1-ton trucks is 12 months/18,000 miles from original date of purchase. This is a general warranty statement and not to be construed as a complete warranty. There is NO warranty on vehicles modified from stock.
Core Charge
$1,500.00
Dimensions
60 × 40 × 24 in
Vehicle Fitment
2008 Ford F-350 Super Duty
2009 Ford F-350 Super Duty
2010 Ford F-350 Super Duty
2011 Ford F-350 Super Duty
2012 Ford F-350 Super Duty
2013 Ford F-350 Super Duty
2011 Ford F-350
2012 Ford F-350
2013 Ford F-350
2014 Ford F-350 Super Duty
2014 Ford F-350
2015 Ford F-350 Super Duty
2015 Ford F-350
2016 Ford F-350 Super Duty
2016 Ford F-350
Fitment Qualifiers
with Dual Rear Wheels (DRW)
with Posi-Traction
with 4.30 Gear Ratio
Standard Wheelbase
Application Summary
2008-2016 Ford F-350 Super Duty Leaf Cab & Chassis
2011-2016 Ford F-350 Leaf Cab & Chassis
Category
Driveline and Axles
Differential
Part Type
Differential
Brand
US Powertrain
Color
Black
Material
Steel/Iron
Axle Type
DANA 80
Position
Rear
Cover Bolt Quantity
10
Cover Included
Yes
Gear Ratio
4.30
Grade Type
Remanufactured
Mounting Hardware Included
No
Prop 65 - Long Label
This product may contain a chemical known to the state of California to cause cancer or birth defects. www.p65warnings.ca.gov
Prop 65 - Short Label
WARNING: Cancer – www.p65warnings.ca.gov
Prop 65 Y/N
Yes
Ring Gear Outside Diameter
11.25
